ToughEco™ is Tough Glass's range of insulated glass units (IGUs), designed to improve thermal performance, energy efficiency and year-round comfort.
Manufactured in Perth, Western Australia, ToughEco™ units are custom built by sealing two or more panes of glass with a spacer system and insulating cavity to reduce heat transfer, minimise condensation and create more comfortable indoor environments. Available in four performance levels, the ToughEco™ range offers solutions from standard double glazing through to advanced Low-E insulated glass, allowing you to select the most suitable configuration for your project's thermal, acoustic and solar performance requirements.
Improves thermal insulation and energy efficiency.
Helps reduce heating and cooling costs.
Reduces condensation.
Improves acoustic performance when combined with the appropriate glass configuration.
Available in a range of performance levels for residential and commercial projects.
Manufactured to custom sizes and configurations in-house.
Our entry-level insulated glass unit, manufactured using standard glass without Low-E coatings. ToughEco™ Lite provides improved thermal performance over single glazing and is ideal where enhanced insulation is required at an economical price point.
Standard double or triple glazed unit.
Improved thermal performance over single glazing.
Available with a range of glass types.
Optional Argon gas fill.
Available with Thermoplastic Spacer (TPS), Super Spacer® or Aluminium spacers.
ToughEco™ Tech combines an insulated glass unit with KeneticPlus hard coat Low-E glass , delivering improved thermal insulation while maintaining excellent durability and processing flexibility.
KeneticPlus hard coat Low-E glass.
Improved thermal insulation.
Reduced heat transfer.
Available in a range of KeneticPlus performance options.
ToughEco™ Plus combines an insulated glass unit with our premium single silver soft coat Low-E glass , providing enhanced thermal performance and excellent natural light transmission.
Single silver soft coat Low-E glass.
Excellent thermal performance.
High visible light transmission.
Improved energy efficiency and occupant comfort.
Our highest-performing insulated glass unit, ToughEco™ Platinum combines an insulated glass unit with advanced double silver soft coat Low-E glass , delivering exceptional thermal insulation and solar control. Available in Clear and Neutral performance options to suit different project requirements.
Double silver soft coat Low-E glass.
Exceptional thermal performance.
Enhanced solar control.
Available in Clear and Neutral options.
Premium energy-efficient glazing solution.
Every ToughEco™ insulated glass unit is manufactured in-house using carefully selected components to suit the specific performance requirements of each project.
By combining a wide range of Tough Glass products, spacer systems, gas fills and sealant options, we can manufacture insulated glass units tailored to achieve the required thermal, acoustic, safety and aesthetic performance.
Our experienced team can assist in selecting the most appropriate configuration for your application.
Double Glazed (IGU) and Triple Glazed Units
Clear, Tinted, Decorative, ToughGuard™, ToughSound™, ToughSwitch™ and KeneticPlus Glass
Thermoplastic Spacer (TPS) (standard), Super Spacer® or Aluminium Spacer
6mm, 8mm, 10mm, 12mm, 14mm, 16mm, 18mm and 20mm*
Air or Argon
Polysulphide (standard), Hot Melt or Silicone
Holes, cut-outs, notches, shapes and polished edges available prior to assembly
100mm x 100mm (Super Spacer) 350mm x 180mm (TPA)
2500mm x 4000mm
2700mm x 5000mm (Aluminium Spacer and Silicone)
*Other spacer thicknesses may be available on request.
Every ToughEco™ insulated glass unit is manufactured using premium components selected to achieve the required thermal, acoustic and structural performance.
The combination of glass, spacer systems, gas fill and sealants all contribute to the overall performance and longevity of the finished unit.
The glass selected plays a significant role in the overall performance of an insulated glass unit. ToughEco™ can be manufactured using a wide range of Tough Glass products, including Clear, Tinted, Decorative, ToughGuard™, ToughSound™, ToughSwitch™ and KeneticPlus Glass , allowing each insulated glass unit to be tailored to suit the project's performance requirements.
Spacer systems separate the panes of glass to create the insulating cavity within the insulated glass unit. The spacer selected influences the thermal performance by reducing heat transfer around the edge of the glazing.
Our standard warm edge spacer system, TPS provides outstanding thermal performance, excellent durability and improved energy efficiency. As our preferred spacer system, it offers superior thermal efficiency and is used as the standard spacer throughout the ToughEco™ range.
Super Spacer® is a flexible warm edge spacer system that provides excellent thermal performance while helping to reduce condensation and improve the overall energy efficiency of the insulated glass unit.
A traditional spacer option suitable for applications where a conventional spacer system is preferred.
The cavity between the panes can be filled with either air or Argon gas. Argon provides improved thermal insulation compared to air, helping increase the overall energy efficiency of the insulated glass unit.
Secondary sealants provide structural strength while protecting the insulated glass unit from moisture ingress and long-term environmental exposure.
Our standard secondary sealant, providing excellent durability and long-term performance.
A fast-curing secondary sealant suitable for a wide range of insulated glass applications.
A high-performance structural sealant used where increased UV resistance, weatherability or structural glazing performance is required.
Visible Light Transmission – The percentage of visible light transmitted through the glass.
Visible Light Reflectance – The percentage of visible light reflected from the glass surface.
Solar Heat Gain Coefficient – Measures how much solar heat passes through the glass. Lower values provide better solar control.
Measures heat transfer through the glazing. Lower values indicate better insulating performance.
Insulated glass units can significantly improve acoustic performance when compared to single glazing. Further improvements can be achieved by varying glass thicknesses, increasing the cavity width or incorporating TG Sound acoustic laminated glass into the insulated glass unit.
Rw (Weighted Sound Reduction Index) is the standard measurement used to rate the sound insulation performance of glazing. The higher the Rw value, the greater the glass's ability to reduce the transmission of airborne noise.
Configuration | Typical Rw Rating |
|---|---|
6mm Clear Float Glass | 31 |
6mm + 12mm Spacer + 6mm | 34 |
10mm + 12mm Spacer + 6mm | 36 |
6mm + 12mm Spacer + 6.5mm TG Sound | 38 |
Overall IGU performance is influenced by the glass configuration, spacer system, gas fill, framing system and installation method.
Thermoplastic Spacer (TPS) is supplied as our standard warm edge spacer system, with Super Spacer® and Aluminium spacer options also available to suit specific project requirements.
Argon gas filling is available to further improve thermal insulation.
Different glass thicknesses and laminated glass constructions can significantly improve acoustic performance.
ToughEco™ insulated glass units are manufactured to suit individual project requirements.
Performance data is available for all ToughEco™ configurations.
An insulated glass unit (IGU) is the technical name for what is commonly referred to as double glazing. It consists of two or more panes of glass separated by a sealed spacer and insulating cavity to improve thermal and acoustic performance.
Unlike standard off-the-shelf double glazing, every ToughEco™ insulated glass unit is custom manufactured in Perth, Western Australia to suit your project's specific performance requirements. With multiple Low-E options, custom laminated glass, decorative glass, acoustic glass and a range of spacer systems available, ToughEco™ provides a tailored glazing solution rather than a one-size-fits-all product.
Yes. ToughEco™ insulated glass units can be manufactured using a wide range of glass types, thicknesses, spacer options and gas fills to suit your project's performance requirements.
Argon is an inert gas used within the cavity of an insulated glass unit to improve thermal insulation. When combined with Low-E glass, it helps reduce heat transfer and improve the overall energy efficiency of the window.
Warm Edge spacers are manufactured from less conductive materials than traditional aluminium spacers, helping to reduce heat transfer around the edge of the insulated glass unit and improve overall thermal performance.
Each ToughEco™ product is designed to suit different performance requirements. ToughEco™ Lite – Standard insulated glass unit without Low-E coatings. ToughEco™ Tech – Incorporates KeneticPlus hard coat Low-E glass. ToughEco™ Plus – Features a premium single silver soft coat Low-E glass. ToughEco™ Platinum – Our highest-performing IGU, incorporating double silver soft coat Low-E glass in either Clear or Neutral options. If you're unsure which product is best suited to your project, our team can recommend the most appropriate solution.
Yes. The width of the spacer cavity influences the thermal and acoustic performance of the insulated glass unit. Our team can recommend the most appropriate cavity size based on your project requirements.
Yes. ToughEco™ insulated glass units can contribute to improving the thermal performance of a home and may assist in meeting the energy efficiency requirements for 7-Star NatHERS-rated homes . The most suitable ToughEco™ configuration will depend on the project's glazing design, orientation, framing system and overall building performance. Our team can assist in selecting an appropriate glazing solution for your project.
